4G Router Specifications
Get known of Outdoor 4G Router on the technical specification, electrical parameter, working frequency, upload speed, download speed, wireless network speed, advanced chipset, powerful Wi-Fi booster, IP67 rated hardware, high-gain antenna, and even more.
Hardware
| CPU: | Qualcomm Atheros QC9531 |
| Frequency: | 650MHz |
| Memory: | 128MB |
| Flash: | 16MB |
| SIM Card: | Standard SIM card (25x15mm) **Exclude** |
| LAN Port: | 1x10/100Mbps RJ45 port on PoE injector |
| Indicator: | Power & system |
| Consumption: | < 3 Watt |
| Temperature: | Working: -30 to 80°C Storage: -50 to 95°C |
| Humidity: | 10%~90% RH |
| Installation: | Pole mounted |
External Antenna
| 4G Omni Antenna: | Frequency: 698~960 / 1710~2700MHz Gain: 3~4dBi / V.S.W.R.: ≤ 2.5 |
| Wi-Fi Antenna: | Frequency: 2400~2500MHz Gain: 5dBi / V.S.W.R.: ≤ 2.5 |
| Measurement: | Φ21×178mm |
| Connector: | N-male |
| Polarization: | Vertical |
| Impedance: | 50 Ω |
| Max Input power: | 10 Watt |
Wi-Fi Booster
| Wi-Fi standards: | IEEE 802.11 b/g/n & IEEE 802.3u |
| Transmission rate: | 300Mbps by 2T2R MIMO Wi-Fi |
| Frequency: | 2412~2484 MHz |
| Channel: | 1~13 |
| Bandwidth: | 20/40 MHz or Auto |
| Output power: | 802.11n: 23±2dBm for OFDM mode 802.11g: 25±2dBm for OFDM mode 802.11b: 27±2dBm for CCK mode |
| Wi-Fi mode: | 11b / 11g / 11n only 11b/g mixed or 11b/g/n mixed |
| Concurrent user: | 57 users |
Software
| Bootloader: | U-Boot v1.1.3 |
| Firmware: | OpenWrt v15.05.01 |
| Computer: | Windows XP Vista 7 8/8.1 MAC OS OS X10.7+ |
PoE
| Input power: | PoE: 48Volt |
| PoE standard: | 802.3af/at |
| Cable length: | Support 100 meters |
| Wiring: | Ethernet 1,2,3,6 / DC+ 4,5 / DC- 7,8 |
Worldwide Cellular Modems
| SKU: | Y4E / Y4U | Y4O | Y6E / Y6U / Y6O |
| LTE Category: | CAT 4 | CAT 4 | CAT 6 |
| 4G FDD Bands: | B1/B3/B5/B7/B8/B20 DL150 / UL50 Mbps |
B1/B2/B3/B4/B5/B7/B8/B28 DL150 / UL50 Mbps |
B1/B3/B5/B7/B8/B20/B28/B32Rx
DL300 / UL50 Mbps |
| 4G TDD Bands: | B38/B40/B41 DL130 / UL30 Mbps |
B40 DL130 / UL30 Mbps |
B38/B40/B41 DL260 / UL28 Mbps |
| Working Area: | Europe, Africa, Middle East, Korea, Thailand, India | Australia, New Zealand, Brazil, Asia, Latin America |
EMEA: Europe, Middle East, Africa
APAC: Asia-Pacific (Excluding Japan and CMCC) & Brazil |
EMEA & APAC Standard
| SKU: | Y4A | Y4V | S6A |
| LTE Category: | CAT 4 | CAT 4 | CAT 6 |
| 4G Bands: | FDD LTE – B2/B4/B12 DL150 / UL50 Mbps |
FDD LTE – B4/B13 DL150 / UL50 Mbps |
B1/2/3/4/5/7/8/12/13/20/25/26/29/30/B41
DL300 / UL50 Mbps |
| Working Area: | North America | North America |
North America (USA and Canada)
|
American Standard
